Escea DL850 - Fitting the Bevelled Sided Fascia Panels

B
ACDEFGSERVICE
35
F2 Fitting the Bevelled Sided Fascia Panels
Step 1: Ensure the glass and all glass retainers are
securely fitted.
NOTE: If the glass gasket requires a replacement, call
your nearest Escea agent who will ensure the part is
replaced with the correct type. In the event that the
glass is broken by impact, purchase the replacement
from an authorised Escea agent only.
Step 2: Attach the Bevelled Outer Fascia Bracket
to the top lid as shown below.
Step 3: Fit the Bevelled Outer Fascia brackets to
the bottom left and right sides of the appliance as
shown.
STEP 8
STEP 8
