3.2 Indicators in pH measurement screen
In pH measurement mode, the meter displays pH and temperature reading.
- END OF pH SECTION -
Item Description
1 Measurement mode indicator
2 Appears when the reading is stable
3 Appears when the reading is on hold
4 pH reading
5 Units of measurement
6 Temperature reading & units
7 Temperature compensation mode
8 pH HI & LO Alarm limits
9 pH Alarm indicator
10 Calibration Due indicator
11 Response time of the pH probe
12 Calibrated Points
1
4
6
8
12
3
2
5
9
11
10
7
