55
7. Press ESC (F4) to go to measurement mode. The meter shows the relative
mV reading of the solution in measurement mode, if offset is not zero.
2.2 Calibration Report
Calibration report gives you information on calibration. It includes date & time on
which the last calibration was done and the offset.
2.2.1 To View Calibration Report:
1. From mV measurement mode, press left or right arrow key to navigate
to other available functions until you see REPO function in the LCD
2. Press REPO (F2) key. The calibration report is shown in the display.
3. Press PRIN (F2) to transfer the calibration report to the computer.
3. mV Measurement Mode
In mV measurement mode, the meter displays mV and temperature reading.
Depending on application, you can connect a suitable ORP probe to the meter or use
the pH probe.
3.1 Indicators in mV measurement mode
Figure 22 : mV Measurement Screen
1
4
5
6
7
3
2
Note: The function of the keys available on the mV calibration/ report
screen is same as previously described in pH calibration with a user-
defined buffer section.
