39
4 DVR CONFIGURATION
This chapter will walk you through the DVR Menu Settings step by step and show you how to set the DVR
for your specific application.
4.1 CONFIGURATION MENU
1. To bring up the Main Menu, press the “Menu” key on the front panel or right-click with the USB mouse
to bring up the OSD menu bar.
2. Press “Enter” or left-click on the “Configuration” icon “ ” to enter the Configuration Menu. Log in if
necessary (see Section 3.2 LOGIN above).
4.2 EXPRESS
The Figure 4-1 Express Menu is a screenshot of the EXPRESS SETTING MENU. This menu is used to
configure global express settings for all cameras. For example, if user selects Event Only in Record Mode
and presses the “Apply” button, all 4/9/16 cameras will be set to Event only. If user selects Blank in
Recording Mode and presses the “Apply” button, cameras will keep their own current individual record
settings without any changes.
Figure 4-1 Express Menu
Chapter
4
