Model 5600MSC Master Clock/SPG Manual
TECHNICAL DESCRIPTIONOPERATION
Revision 1.6 Page 3-69
1. Press the GENERAL key to enter the GENERAL SETUP menu. Use the arrow keys (Ï, Ð) or
turn the
SHAFT ENCODER knob to display the Set System Date menu item and press the
SELECT key. The current system date will be displayed in yy/mm/dd format with the year digits
blinking. If you want to exit the date entry mode press the
ESC key at any time.
2. Press any numeric key to enter a new value into the right digit of the blinking digit pair or press
the
SELECT key to advance to the next digit pair. Press another numeric key to shift the first
digit to the left and enter a new value into the right digit of the blinking digit pair. The month digit
pair will now be blinking
3. Repeat step 2 for the month and day.
4. When you are finished entering the day, all the digits will stop blinking and the front panel
display will show the word
Enter at the right. Press the SELECT button to set the system date.
The front panel display will show the message
System Date Set for about 1 second.
3.7.14. Setting The User Bits in Manual User Bit Mode
GENERAL
Set User Bits
00000000 UB
When the
User Bit Mode menu item is set to Manual, the user can set the
User bits of the time code outputs using the following procedure. (see
section 3.7.15)
1. Press the
GENERAL key to enter the GENERAL SETUP menu. Use the arrow keys (Ï, Ð) or
turn the
SHAFT ENCODER knob to display the Set User Bits menu item and press the SELECT
key. The current user bits will be displayed with the leftmost digit blinking. If you want to exit the
user bit entry mode press the
ESC key at any time. Note that in order to change the user bits,
the USER BIT MODE must be set to
Manual entry.
2. Press any numeric key to enter a new value into the blinking digit or turn the
SHAFT ENCODER
knob, and use the arrow keys (
Ï, Ð) to advance to the next digit. The range of each digit is 0 -
9 and a – f. The
SHAFT ENCODER knob must be used for digits a – f.
3. Repeat step 2 for each digit.
4. When you are finished entering the user bits, press the
SELECT button to set the user bits.
