Model 5600MSC Master Clock/SPG Manual
Page 3-6
Revision 1.6 OPERATION
3.3.4. Modem Status
These messages show the current modem status when a call is not in progress.
Modem booting The modem is going through its power up sequence.
Last mdm 5d11:20 Time since last successful modem connection and time update.
Shows 0 to 9 days, hours and minutes. If greater than 10 days shows
Last mdm >10days
Last mdm >10days Time since last successful modem connection greater than 10 days.
Xx sec to redial The previous attempt failed, and the modem will try again in xx
seconds.
Setting volume The modem is changing its speaker volume
These messages show the current action when the modem is initiating a call.
Calling The modem is dialing out.
No dial tone There is no dial tone when the modem tries to dial out.
Connecting The remote system has answered, and they are negotiating a
connection speed.
Getting time The modem is getting time information from a remote system.
After an attempt to connect a modem status message will appear for ten seconds. The status
messages are:
FAIL TIMED OUT No connection was established.
FAIL NO DIALTONE No connection was established because no dial tone detected.
FAIL LINK POOR Poor connection, data was too erratic to establish a valid time.
FAIL LOOPBACK The loop back time was incorrect – indicates a bad telephone line.
SUCCESS Indicates a successful connection and time update.
These messages show the current action when the modem is answering a call.
Answering The modem is answering a remote system’s incoming call, and is
negotiating a connection speed.
Sending time The modem is sending time information to a remote system.
Hanging up The modem is hanging up, either because the call was complete, or
because it timed out.
3.3.5. NTP Messages
Axxx.yyy.zzz.aaa
The current I.P. Address of the 5600MSC in decimal dot format.
Gxxx.yyy.zzz.aaa The current I.P. Gateway Address of the 5600MSC in decimal dot
format.
Mxxx.yyy.zzz.aaa The current I.P. NetMask Address of the 5600MSC in decimal dot
format.
3.3.6. LTC 1 Output Power Status Messages
These messages are only shown if the LTC 1 Power menu item is set to L1 power on. See section
3.6.1.1.
