Model 5600MSC Master Clock/SPG Manual
Page 4-2
Revision 1.6 TECHNICAL DESCRIPTION
4.1.4. Genlock Input
Type:
autodetects standard
SMPTE 170M (NTSC-M), ITU-R BT.470-6 (PAL-B) Colour Black 1 V p-p
Composite Bi-level sync (525i/59.94 or 625i/50) 300 mV
HD Tri-level Sync (same HD standards as sync outputs)
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: Max: 2 V p-p video
Min: Sync level 150 mV
Frequency Lock Range: ±50ppm from nominal
Termination: High impedance – external termination required
Return Loss: >25dB to 10MHz (with external 75 ohm termination)
4.1.5. Communications and Control:
Serial Port:
Connector:
Female DB-9
Level: RS232
Baud Rate: 57.6 Kbaud
Format: 8 data bits, no parity, 2 stop bits
Modem: (M option installed)
Connector:
RJ-11 telephone jack
Baud Rate: 300 baud Bell 103 compatible
Ethernet: (NTP port with T option installed)
Network Type:
Fast Ethernet 100 Base-TX IEEE 802.3u standard for 100 Mbps baseband
CSMA/CD local area network
Ethernet 10 Base-T IEEE 802.3 standard for 10 Mbps baseband CSMA/CD local
area network
Connector: RJ-45
NTP Standard: RFC-1305 compliant, broadcast and server mode support.
Must be referenced to GPS or via modem
4.1.6. GPS Receiver (G option installed)
Temperature:
-40°C to +70°C
Humidity: 95% R.H. Condensing at 60°C
Dimensions: 5.8“ D x 3.9” H (147mm x 100mm)
Cable Options: Standard 50’
Optional 100’ (order WA-T76)
Optional 400’ (order WA-T11)
