Model 5600MSC Master Clock/SPG Manual
TECHNICAL DESCRIPTIONOPERATION
Revision 1.6 Page 3-33
Test Signal Name Test Signal Name
SMPTE Color bars FCC Multiburst
75% Color bars FCC Composite
100% Color bars Chroma Freq. Response
Composite Signal NTC 7 Combination
2T Pulse and Bar NTC 7 Composite
SinX/X Pulse Multipulse
20% White Window 60% Ext Multiburst
50% White Window 60% Multiburst
80% White Window 2.5 MHz Bowtie
100% White Window 5 Step
Y Multipulse Y Ramp
Shallow Y Ramp Valid ramp
Shallow Ramp Pathological
Modulated Ramp White
10 Y Step Grey
10 Step Black
Convergence Pattern
Table 3-3: 525 Line Test Signal Selection
Test Signal Name Test Signal Name
75% Color bars Limited ramp
100% Color bars 5 Step
Composite Signal Y Only 10 Step
Pathological 10 Step
Convergence Pattern 60% Y Sweep
2T 4T 20T Pulse 60% Sweep
CCIR 331 100% Y Sweep
CCIR 330 100% Sweep
CCIR 18 SinX/X Pulse
CCIR 17 60% Multiburst
Y Ramp 2.5 MHz Bowtie
Shallow Y Ramp White
Shallow Ramp Grey
Modulated Ramp Black
Table 3-4: 625 Line Test Signal Selection
