TECHNICAL DESCRIPTION
Revision 1.6 Page 4-3
4.1.7. DARS & AES Test Generator Outputs (STG option installed)
Standard:
Unbalanced: SMPTE 276M Single ended AES (24 bits)
Balanced: AES3-1992 (24 bits)
Number of Outputs:
DARS:
1 unbalanced, 1 balanced
AES Test Gen: 1 unbalanced, 1 balanced
Connector:
Unbalanced:
BNC per IEC 60169-8 Amendment 2
Balanced: Removable Terminal Strip
Sampling Rate: 48 kHz
Impedance:
Unbalanced:
75 Ohms unbalanced
Balanced: 110 Ohms balanced
Signal Level:
Unbalanced: 1 V p-p into 75 ohms
Balanced: 4V p-p unterminated
Return Loss: >25dB to 10MHz (with external 75 termination)
AES Tones: Menu selectable
4.1.8. Analog Composite Video Test Signal Generator (STG option installed)
Standard:
SMPTE 170M (NTSC-M), ITU-R BT.470-6 (PAL-B)
Number of Outputs: 1
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: 1V p-p nominal
DC Offset: 0V ±0.1V
Output Impedance: 75 Ohms
Return Loss: >35dB to 10MHz (with external 75 termination)
SNR: > 75dB
4.1.9. Analog Audio Tones Generator (STG option installed)
Number of Outputs:
1 Left and right channel pair
Type: Balanced analog audio
Connector: 6 pins on 12 pin removable terminal strip
Output Impedance: 66 Ohms balanced
Signal Level: -20 to +2 dBu into 10 Kohm load
Audio Tones: Menu selectable – same as AES tones
