Model 5600MSC Master Clock/SPG Manual
TECHNICAL DESCRIPTIONOPERATION
Revision 1.6 Page 3-31
OUTPUT
ANALOG TEST GEN
ATG Fine phs
A
TG fn ph= 0.0%
This menu item is used to set the phase of the video output in fractions of a
sample. 100.0% is equivalent to one sample period.
3.6.3.3. Configuring the Analog Video Test Generator On Screen Message Display
The 5600MSC Analog Video Test generator has a programmable 16-character text message that may
be used to display a source identification message or any other information on the screen.
3.6.3.3.1. Editing the On Screen Message Display
OUTPUT
ANALOG TEST GEN
ATG Message Text
The
ATG Message Text menu item is used to edit the text message. When
you enter the
ATG Message Text menu item, the actual text message is
displayed on the top line of the analog video test generator output and the
front panel of the 5600MSC.
To edit the message, turn the
SHAFT ENCODER knob to change the
blinking character. Press the arrow keys (
Ï, Ð) to change to the next or
previous character. Press the
SELECT button when done. Note that blank
spaces do not blink.
3.6.3.3.2. Positioning the On Screen Message Display
OUTPUT
ANALOG TEST GEN
ATG Message H
AT
G message h 01
The
ATG Message H menu item is used to position the text message
horizontally on the character raster. Use the arrow keys (
Ï, Ð) or turn the
SHAFT ENCODER knob to move the message horizontally. Press the
SELECT button to save the new position or press the ESC button to exit the
ATG Message H menu without saving the new position.
OUTPUT
ANALOG TEST GEN
ATG Message V
A
TG message v 01
The
ATG Message V menu item is used to position the text message
vertically on the character raster. Use the arrow keys (
Ï, Ð) or turn the
SHAFT ENCODER knob to move the message vertically. Press the
SELECT button to save the new position or press the ESC button to exit the
ATG Message V menu without saving the new position.
3.6.3.3.3. Enabling the On Screen Message Display
OUTPUT
ANALOG TEST GEN
ATG Message En
A
TG message off
A
TG message on
The
ATG Message En menu item is used to turn the Analog Video Test
Generator On Screen Message Display on and off.
