Model 5600MSC Master Clock/SPG Manual
Page 3-2
Revision 1.6 OPERATION
ESC When in one of the Setup menus the ESC key is used to move to the next lower sub-
menu levels or to select a menu parameter that is to be changed. The
ESC key is also
used to cancel the process of entering numeric data.
Ï, Ð, SHAFT ENCODER When in one of the Setup menus, the Ï and Ð arrow keys are used to
move to various items in the menu system. Turning the
SHAFT ENCODER knob
clockwise (to the right) has the same effect as pressing the
Ï key. Turning the SHAFT
ENCODER
knob counter-clockwise (to the left) has the same effect as pressing the Ð
key (See also section 3.4)
3.1.2. The Display Button Group
The Display pushbutton group consists of the DISPLAY and STATUS keys and is used to select the
information being displayed on the front panel when you are not in one of the
Setup menus. After you
press either the
DISPLAY or STATUS keys, you can use the Ï, Ð keys or the SHAFT ENCODER
knob to select the
Status or Display items.
DISPLAY Allows you to quickly view the various times being generated on the LTC and video
outputs, as well as the system time and date. (See section 3.2)
STATUS Allows you to quickly view fault messages, the status of the power supplies, and GPI
inputs. (See section 3.3)
3.1.3. Panel Lock Key Functions
PANEL LOCK
Pressing this key will lock the front panel. The LED beside the PANEL LOCK key will
come on indicating that the front panel keys are disabled. Pressing both the
PANEL
LOCK
and SELECT key again will return the front panel keys to their normal functions
and the PANEL LOCK LED will go Off. The
STATUS and DISPLAY keys will still be
functional when the PANEL LOCK is On.
3.1.4. Shaft Encoder Knob
The shaft encoder’s function is to select various menu items or change the value a menu item’s
parameter value.
Ï, Ð, SHAFT ENCODER When in one of the Setup menus, the Ï and Ð arrow keys are used to
move to various items in the menu system. Turning the
SHAFT ENCODER knob
clockwise (to the right) has the same effect as pressing the
Ï key. Turning the SHAFT
ENCODER
knob counter-clockwise (to the left) has the same effect as pressing the Ð
key. Menu parameter values will increase for clockwise rotations of the knob and
decrease for counter-clockwise rotations.
