Model 5600MSC Master Clock/SPG Manual
TECHNICAL DESCRIPTIONOPERATION
Revision 1.6 Page 3-51
Example 1: Create a sequence to have a single 1 second duration 1 kHz beep once per hour at the half
hour and a double 1 second beep once per hour at the hour.
1. Set the
Audio 1 Start Time to 99:00:00:0. Set the Audio 1 Sound Type to Beep. Set the Audio
1 Sound Freq
to 1.0 kHz. Set the Audio 1 Duration to 1 sec.
2. Set the Audio 2 Start Time to 99:30:00:0. Set the Audio 2 Sound Type to Beep. Set the Audio
2 Sound Freq
to 1.0 kHz. Set the Audio 2 Duration to 1 sec.
3. Set the
Audio 3 Start Time to 99:30:02:0. Set the Audio 3 Sound Type to Beep. Set the Audio
3 Sound Freq
to 1.0 kHz. Set the Audio 3 Duration to 1 sec.
3.6.12. Configuring the DARS and AES Outputs (STG Option only)
3.6.12.1. Setting The Phase of the AES and DARS Outputs (STG Option only)
There are two registers that are used to set the phase of the AES and DARS outputs.
"
When adjusting the AES/DARS Output phase menu items, the phase of the AES
and DARS outputs will be immediately changed. Use these controls with caution,
as they will affect the overall timing of devices connected to the AES and DARS
outputs.
OUTPUT
AES/DARS OUTPUT
ES Coarse Phase
AES course = 1
This menu item is used to set the phase of the AES and DARS outputs in
coarse steps. This control affects both AES and DARS together.
OUTPUT
AES/DARS OUTPUT
AES Fine Phase
AES fine = 1
This menu item is used to set the phase of the AES and DARS outputs in
fine steps. This control affects both AES and DARS together. This control is
not valid if AES Lock Type is set to NTSC
