OUTPUT
SYNC 1 OUTPUT
S1 1080i/60
S1 1080i/50
S1 1080p/24sf
S1 1080p/25
S1 720p/50
S1 720p/24
S1 1080p/24
S1 625i/48
S1 1080p/24
S1 720p/60
Tri-level sync in the 24, 25, 30 and 60 frames per second high definition
standards is available when the respective
Bank Setup menu item is set to
HD 1.000.
OUTPUT
SYNC 1 OUTPUT
S1 1080i/59.94
S1 1080p/23.98sf
S1 720P/23.98
S1 625i.47.95
S1 1080p/23.98
S1 720p/59.94
Tri-level sync in the 23.98 and 59.94 frames per second high definition
standards is available when the respective
Bank Setup menu item is set to
HD 1.001.
3.6.2.3. Configuring the VITC Generator for the Colour Black Outputs
3.6.2.3.1. Enabling VITC on the Video Output
OUTPUT
SYNC 1 OUTPUT
Sync 1 VITC
S1 vitc off
S1 vitc on
This menu item selects whether there will be vertical interval time code
(VITC) on the sync output.
This menu item is only applicable when the
Sync Standard is set to the
PAL-B or NTSC-M standards. The menu item will show the message
S1 no vitc in hd when the Sync Standard is set to one of the high
definition video standards.
"
When the Time Reference is set to LTC In or VITC In then the VITC Enable menu
item will be forced to vitc off if the Sync 1 frame rate is different than the rate of the
incoming LTC or VITC respectively.
