Model 5600MSC Master Clock/SPG Manual
INSTALLATION
Revision 1.6 Page 2-11
"
When making your own extender cable be sure to use low capacitance twisted pair
cable and adhere to the pairing shown in Figure 2-5.
2.5.3. System Startup
At power up, the smart antenna will automatically begin to acquire and track the GPS satellite signals.
From a cold start, the smart antenna will normally take from 2 to 5 minutes to lock on to sufficient
satellites to accurately determine the time. During this time the GPS STATUS display on the front
panel will show the various stages of initialization. For complete information on configuring the
5600MSC operate with the GPS Smart antenna see section 3.8 of this manual
