Model 5600MSC Master Clock/SPG Manual
Page 3-46
Revision 1.6 OPERATION
"
The front panel display will show WARNING LIVE CTL for 0.6 seconds to indicate
that changing the HD Test Generator test signals will affect the Analog Test
Generator output immediately. You do not have to press the SELECT button to
accept the new values.
"
Some test signals are not available on certain video formats.
Test Signal Name Test Signal Name
Y Multipulse Valid Ramp
Multipulse Clean Aperture with Graticule
100% Y MB: 20, 22, 24, 26, 28, 30 Circle with Centre Cross
100% Y MB: 10, 12, 14, 16, 18, 20 Clean Aperture with Centre
100% Y MB: 1, 2, 4, 6, 8, 10 MHz Clean Aperture
60% Y MB: 20, 22, 24, 26, 28, 30 Production Aperture
60% Y MB: 10, 12, 14, 16, 18, 20 12% White Window
60% Y MB: 1, 2, 4, 6, 8, 10 20% White Window
100% MB: 20, 22, 24, 26, 28, 30 MHz 50% White Window
100% MB: 10, 12, 14, 16, 18, 20 MHz 80% White Window
100% MB: 1, 2, 4, 6, 8, 10 MHz 100% White Window
60% MB: 20, 22, 24, 26, 28, 30 MHz Split Field Bars
60% MB: 10, 12, 14, 16, 18, 20 MH Full Field Pluge
60% MB: 1, 2, 4, 6, 8, 10 MHz SMPTE Color Bars
60% Y Line Sweep 15 to30 MHz 75% Color bars with pluge
60% Y Line Sweep to 30 MHz 100% Color bars with pluge
60% Line Sweep 15 to 30 MHz Lab Bars, Moving Box
60% Line Sweep to 30 MHz Lab Bars
Grey 75% bars, 100% white
Grey (all data bits active) 75% Color bars
SDI Checkfield 100% Color bars
Bouncing Box White Field
10 Frame Sequence Black
Five Frame Sequence 480P Composite Signal
Four Frame Sequence 480P Black/White Frames
Field ID 480P White Frame
Frame ID 480P Production Aperture
Bowtie 480P SMPTE Color Bars
5 Step Staircase
Valid 5 Step
Table 3-6: HD SDI Test Signal Selection
