High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
Page 96 Revision 1.8 SPECIFICATIONS
EMX3-FR:
AC Mains Input: Auto ranging, 100  240 VAC, 50/60 Hz
Max Operating Current: 4.6 A (@ 100 V/60Hz), 1.85A (@ 240 V/50Hz)
Max Power Consumption: 450 W
Max Module Load: 360 W (24 W per slot)
Power Supply Configuration: 1 supply standard, optional redundant supply requires separate inlet
Connector: IEC 60320 - 1 per power supply
3.1.14. Physical
3000FR:
Height: 10.5” (266mm)
Width: 19.0” (483mm)
Depth: 14.5” (368mm)
Module Capacity: 15 single slot EMR series modules
Weight Approx.: 34.8lbs (15.8kg) with 2 power supplies, no slots occupied
Approximately: 64.0lbs (29kg) with 2 power supplies, all slots occupied
EMX6-FR:
Height: 10.5” (266mm)
Width: 19.0” (483mm)
Depth: 15.75” (400mm)
Module Capacity: 15 single slot EMR series modules
Weight Approx.: 34.8lbs (15.8kg) with 2 power supplies, no slots occupied
Approximately: 64.0lbs (29kg) with 2 power supplies, all slots occupied
EMX3-FR:
Height: 5.25” (133mm)
Width: 19.0” (483mm)
Depth: 15.75” (400mm)
Module Capacity: 5 single slot EMR series modules
Weight Approx.: 17.4lbs (7.9kg) with 2 power supplies, no slots occupied
Approximately: 32.0lbs (14.5kg) with 2 power supplies, all slots occupied
