5.1.2.1. Audio Channel Control VistaLINK
®
Control Parameters
The following audio channel control parameters can be remotely controlled through the VistaLINK
®
interface.
Delay: This control allows the user to set the audio delay. (This control is available for +DLY option only.)
The value can be between 0 to 1364ms in one sample increments.
Audio Tone Gen Enable: This control allows the user to set the internal tone generator.
Audio Tone Gen Freq: This control allows the user to set the frequency of the tone generator. Possible
options are 10Hz, 100Hz and 1000Hz.
Audio Tone Gen Gain: This control allows the user to set the gain of the tone generator. The value can
be between -80 to 0 dBFS in 1 dBFS increments.
