EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
Page 82 Revision 1.8 COMPONENT OVERVIEW
MADI Present LEDs
TDM Present LEDs
Audio Packet without LSID
LSID with no Audio Packet
Switches the display to view firmware version, IP address A, IP address B
Table 2-33 : Description of EMR-IO8-MADI Card Edge
2.3. INSTALLING AND REMOVING THE MODULES
2.3.1. Installing the Module Rear Plate
In most cases, the EMR frame will already have the modules and rear plates installed within the frame.
However, when modules and rear plates need re-positioning, or when additional modules are purchased,
proper module/rear plate installation is required.
Each EMR module is shipped with a matching rear panel plate that houses the appropriate connectors for
that module.
To Install the Rear Plate:
1. Locate the specific slot in the frame and remove any filler plates.
2. Install the rear plate over the open slot by first fitting the plate then tightening the two lock-screws.
3. Fasten the third screw in the middle of the rear plate. (Only on 3000FR)
4. Tighten the screws after the main module is installed.
CAUTION: If any of the screws for the rear plate are missing, please contact
Evertz immediately for the specification and/or replacement. Using the
incorrect screw can cause thread stripping.
2.3.2. Opening and Closing the Front Panel
In order to insert or remove modules you will have to open the front panel using the following procedure:
1. Turn the two captive screws located on the front panel counter clockwise several turns until they
release completely from the front extrusions.
2. Carefully lower the front panel door so that the front edge of the door is lower than the rear of the door.
