EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
Page 56 Revision 1.8 COMPONENT OVERVIEW
Network Configuration Configuration of Network 1 and 2
SNMP Configuration Configuration of Simple Network Management Protocol.
LTC Port Configuration
Views LTC port routing, port status table, frame reference status, Card ID,
LTC output amplitude and plink status.
Trace - Engineering Only Configured under the supervision of Evertz technical support staff only
Engineering Debug Utility Accessed by Evertz technical support staff only
EMR-IP96(48)-LTC EMR-OP96(48)-LTC
EMR ADMX-48X48
Figure
2-31: Basic LTC Setup with ADMX-48X48
To Next Page
