EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
Page 8 Revision 1.8 COMPONENT OVERVIEW
located near the back of the main module. Depending on which module is installed, the connectors have
different functions. Table
2-1 shows the different I/O configurations available.
LINK MODULE TDM3 TDM4 TDM5/39 TDM6/40 MADI1/68 MADI2/69
(A-EMR-AES-UNBALT3)
AES IN 40 AES IN 68 AES IN 69
Table 2-1: Link Module Options for EMR-IP96 (48)-AESU
