evertz EMX3-FR - Table 2-30: Multi-Card TDM Cables (336 Ports, 7 Card Systems)

EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
Page 76 Revision 1.8 COMPONENT OVERVIEW
Input Card
Connector
From
Output Card
Connector
Card 1 In 1
TDM 5
Card 2 Out 1
TDM 1
Card 1 In 2
TDM 6
Card 3 Out 1
TDM 1
Card 1 In 3
MADI 1
Card 4 Out 1
TDM 1
Card 1 In 4
MADI 2
Card 5 Out 1
TDM 1
Card 1 In 5
REF_IN 2
Card 6 Out 1
TDM 1
Card 1 In 6
REF_IN 1
Card 7 Out 1
TDM 1
Card 2 In 1
TDM 5
Card 1 Out 1
TDM 1
Card 2 In 2
TDM 6
Card 3 Out 2
TDM 3
Card 2 In 3
MADI 1
Card 4 Out 2
TDM 3
Card 2 In 4
MADI 2
Card 5 Out 2
TDM 3
Card 2 In 5
REF_IN 2
Card 6 Out 2
TDM 3
Card 2 In 6
REF_IN 1
Card 7 Out 2
TDM 3
Card 3 In 1
TDM 5
Card 1 Out 2
TDM 3
Card 3 In 2
TDM 6
Card 2 Out 2
TDM 3
Card 3 In 3
MADI 1
Card 4 Out 3
TDM 2
Card 3 In 4
MADI 2
Card 5 Out 3
TDM 2
Card 3 In 5
REF_IN 2
Card 6 Out 3
TDM 2
Card 3 In 6
REF_IN 1
Card 7 Out 2
TDM 2
Card 4 In 1
TDM 5
Card 1 Out 3
TDM 2
Card 4 In 2
TDM 6
Card 2 Out 3
TDM 2
Card 4 In 3
MADI 1
Card 3 Out 3
TDM 2
Card 4 In 4
MADI 2
Card 5 Out 4
TDM 4
Card 4 In 5
REF_IN 2
Card 6 Out 4
TDM 4
Card 4 In 6
REF_IN 1
Card 7 Out 4
TDM 4
Card 5 In 1
TDM 5
Card 1 Out 4
TDM 4
Card 5 In 2
TDM 6
Card 2 Out 4
TDM 4
Card 5 In 3
MADI 1
Card 3 Out 4
TDM 4
Card 5 In 4
MADI 2
Card 4 Out 4
TDM 4
Card 5 In 5
REF_IN 2
Card 6 Out 5
REF_OUT_2
Card 5 In 6
REF_IN 1
Card 7 Out 5
REF_OUT_2
Card 6 In 1
TDM 5
Card 1 Out 5
REF_OUT_2
Card 6 In 2
TDM 6
Card 2 Out 5
REF_OUT_2
Card 6 In 3
MADI 1
Card 3 Out 5
REF_OUT_2
Card 6 In 4
MADI 2
Card 4 Out 5
REF_OUT_2
Card 6 In 5
REF_IN 2
Card 5 Out 5
REF_OUT_2
Card 6 In 6
REF_IN 1
Card 7 Out 6
REF_OUT_1
Card 7 In 1
TDM 5
Card 1 Out 6
REF_OUT_1
Card 7 In 2
TDM 6
Card 2 Out 6
REF_OUT_1
Card 7 In 3
MADI 1
Card 3 Out 6
REF_OUT_1
Card 7 In 4
MADI 2
Card 4 Out 6
REF_OUT_1
Card 7 In 5
REF_IN 2
Card 5 Out 6
REF_OUT_1
Card 7 In 6
REF_IN 1
Card 6 Out 6
REF_OUT_1
Table 2-30: Multi-Card TDM Cables (336 Ports, 7 Card Systems)
