evertz EMX3-FR - EMR-OP96 (48)-LTC Timecode Output Module

EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
COMPONENT OVERVIEW Revision 1.8 Page 51
Network Configuration Configuration of Network 1 and 2
SNMP Configuration Configuration of Simple Network Management Protocol.
LTC Port Configuration
Views LTC port routing, port status table, frame reference status, frame
reference and plink status.
Trace - Engineering Only Configured under the supervision of Evertz technical support staff only
Engineering Debug Utility Accessed by Evertz technical support staff only
2.2.9. EMR-OP96 (48)-LTC TimeCode Output Module
The EMR-OP96 (48)-LTC is a time code output card for the EMR. It supports 96 or 48 balanced LTC
outputs.
The EMR-OP96 (48)-LTC output card does not require the use of an ADMX for systems with less than
768 LTC outputs. Each LTC output card connects directly to each LTC input card via one of 8 TDM
inputs.
The EMR-OP96-LTC rear panel occupies 2 slots in a frame and has 50-pin D-Sub female connectors as
shown in Figure
2-29. The LTC outputs are interfaced by the six 50-pin D-Sub female connectors. Each
connector supports 16 LTC output signals. The pin out for each connector is shown in Table
2-18. The
TDM inputs all use DIN 1.0/2.3 connectors and are identified using Table
2-17. The sequence in which
input cards are connected to the output card determine the sequence of the LTC inputs. The EMR-OP48-
LTC uses the same rear plate but only the first three 50-pin D-Sub connectors are enabled.
