EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
COMPONENT OVERVIEW Revision 1.8 Page 63
Component Description
Voltage Status
LEDs
This set of LEDs are amber in color and should always be ON
Ethernet 1 LED
This LED is green in color and flashes when there is activity on
Ethernet port 1
Ethernet 2 LED
This LED is green in color and flashes when there is activity on
Ethernet port 2
TDM 1
This LED is green in color and flashes when a valid TDM signal is
detected on TDM input 1 and is solid when it is the primary TDM
TDM 2
This LED is green in color and flashes when a valid TDM signal is
detected on TDM input 2 and is solid when it is the primary TDM
Run/Upgrade
Jumper
This jumper is used to place the module in upgrade mode when
upgrading the firmware
Reset Button
This button resets the module
Table 2-22: Description of EMR-PR48 Card Edge
To Next Page
