EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
COMPONENT OVERVIEW Revision 1.8 Page 19
Network Configuration Configuration of Network 1 and 2
SNMP Configuration Configuration of Simple Network Management Protocol.
Audio Configuration
View of audio channel status, frame reference, board and TDM
information.
Configuring Headphone port, Tone Gen and Audio pair control
Set TDM Version Configuration of TDM versions (TDM v2 is for future use)
Audio Monitor Cast
Configuration of Cast service
Trace - Engineering Only Configured under the supervision of Evertz technical support staff only
Engineering Debug Utility Accessed by Evertz technical support staff only
Note: The default TDM version has to be set to V1; TDM V2 is for future use.
