EMR User's Guide
High Density Modular Audio Router (AES, Analog, MADI, TimeCode, Data)
COMPONENT OVERVIEW Revision 1.8 Page 33
Network Configuration Configuration of Network 1 and 2
SNMP Configuration Configuration of Simple Network Management Protocol.
Audio Configuration
View of audio channel status, frame reference and board information.
Configuration of Headphone port,
Tone Gen, Audio Monitor and MADI
Mode.
Audio ADC/DAC
Configuration
View of Alignment and Calibration tables. Configuration of Alignment.
Set TDM Version Configuration of TDM versions (TDM v2 is for future use)
Audio Monitor Cast
Service Config
Configuration of Cast service
Trace - Engineering Only Configured under the supervision of Evertz technical support staff only
Engineering Debug Utility Accessed by Evertz technical support staff only
Note: The default TDM version has to be set to V1; TDM V2 is for future use.
To Next Page
