Functional characteristics
MIG/MAG welding
Item No.: 099-005073-EWM01 49
5.2.11 Special parameter, “M3.70/M3.71”
The special parameters cannot be viewed directly since they are normally only set and stored once. The
machine control offers the following special functions:
5.2.11.1 Special parameters list
Function Setting options Ex
works
P1 Ramp time for wire inching 0 = normal inching (10s ramp time)
1 = fast inching (3s ramp time)
1
P2 Block program "0" 0 = P0 enabled
1 = P0 blocked
0
P3 PowerControl torch display mode 0 = normal display
1 = alternating display
0
P4 Program limitation Programs 2 to max. 15 15
P5 Special cycle in the special latched
and non-latched operating modes
0 = normal (previous) non-latched/latched
1 = WF3 cycle for non-latched/latched
0
P6
1
Enable special jobs SP1 to SP3 0 = no enabling
1 = enabling of Sp1-3
0
P7 Correction operation, threshold value
setting
0 = correction operation switched off
1 = correction operation on
"Main program (PA)" flashing
0
P8
2
Program changeover with standard
torch
0 = no program changeover
1 = special latched
2 = specific latched special (n cycle active)
0
P9 Lat. and sp. lat. tapping start 0 = no latched tapping start
1 = latched tapping start possible
0
P10
2
One or two-wire feed operation 0 = single operation
1 = dual operation, this unit is the "master"
2 = dual operation, this unit is the "slave"
0
P11 Special latched tapping time 0 = tapping function switched off
1 = 300ms
2 = 600ms
1
P12
2
JOB list changeover 0 = task-oriented JOB list
1 = actual JOB list
2 = actual JOB list, JOB changeover activated
via accessories
0/1
4
P13
2
Lower limit
remote JOB changeover
Lowest JOB that can be selected using
PowerControl 2 torches.
129
P14
2
Upper limit
remote JOB changeover
Highest JOB that can be selected using
PowerControl 2 torches.
169
P15 Hold function 0 = hold values are not displayed
1 = hold values are displayed.
1
Key
3
Software key switch 0 = system complete
1 = system not complete
1
1) PHOENIX EXPERT range only
2) PHOENIX EXPERT und PROGRESS ranges only
3) PHOENIX BASIC range only
4) See note in the relevant section of this chapter
