Excell H3 Series User Manual

48
EXCELL PRECISION CO., LTD.
0300403
4
ZSME200000051
3-2-1 External Weight Calibration
Zero value can be calibrated separately from the weight calibration value.
No weight display Internal value of no weight display
Calibration poises value (weight value of fully capacity) Internal value of full capacity display
Poises weight value on platter Internal value


 key ⇒
⇒⇒
⇒ Exit
CE key ⇒
⇒⇒
⇒ Move the cursor leftward
TARE key ⇒
⇒⇒
⇒ Move the cursor rightward
MC key ⇒
⇒⇒
⇒ Enter
X X X
.
X X X
X X X X X X
Make sure that no load on platter,
and press MC to read “Zero”
Press PRESET CE to switch calibration unit.
Press . if not intend to calibrate “0”.
Press MC
If there is no temperature IC, the unit weight column will
display .
.
X X X X X X X X X
Use number key 0 ~ 9 to
modify calibration poises value,
place enough poises according to
value entered, and press MC
key to read calibrated internal
value and save into
EEPROM
.
 Calibration poises value entered can not be higher than “
maximum
weighing capacity”.
 Poises weight entered will be compared with internal calibration
poises weight. If the actual weight is more than the entered poises
weight in 1.1~0.9 times, the weight column will display
for 1 second. Re-enter the calibration poises value,
or place the correct weight to operate once again.
 If you do not calibrate weight, press . key to exit without saving
AD data into EEPROM.
.
X X X X X X X X X
Under weight calibration mode, please put on or
remove weight to test. After testing, press MC
key to complete external weight calibration
kg
kg
kg
