Excell H3 Series - Baud Rate Setting

52
EXCELL PRECISION CO., LTD.
0300403
4
ZSME200000051
3-3-1 Baud Rate Setting
 Default setting: ( 9 600 bits/second)
⇒ 600 bits/second
⇒ 1 200 bits/second
⇒ 2 400 bits/second
⇒ 4 800 bits/second
⇒ 9 600 bits/second
⇒ 19 200 bits/second
 If there is free form device, it is 9600 bits/sec transmit.


 key ⇒
⇒⇒
⇒ Exit
CE key ⇒
⇒⇒
⇒ Move the cursor leftward
TARE key ⇒
⇒⇒
⇒ Move the cursor rightward
MC key ⇒
⇒⇒
⇒ Enter
Press MC
Enter parameter 00 ~ 05
according to demand
Press MC key to save
the setting data
Previous setting
