Setting up Your Fiber Inspection Probe and ConnectorMax2 Mobile
30 FIP-400B
Changing the FIP Nozzle (MF-Ready Probes Only)
3. Tighten the retaining nut clockwise.
4. Insert the inspection tip on the MF-Ready probe by aligning the key of
the probe with the notch of the inspection tip.
Note: If you cannot see the notch of the inspection tip, slide the movable part of
the inspection tip with the trigger towards the nozzle.
Removable nozzle
Retaining nut
Inspection tip (movable part)
MF-Ready probe
Trigger
