Introducing the FIP-500 Fiber Inspection Scope
Fiber Inspection Scope 5
LED Indicators Description
LED Indicators Description
Your unit is equipped with a battery LED and a dual-function LED.
Battery LED
The battery LED, located next to the power button, on the side of your unit,
provides you with information about the battery status.
The table below indicates the possible statuses.
Unit Status Meaning
Connected to an
external power
source
Off The external power source does not
provide sufficient power to charge the
battery.
Blue The battery is fully charged.
Blue, blinking – slow
blinking
The battery is charging.
Blue, blinking – fast blinking The battery charge has been
interrupted, possibly because the unit
may not be within the recommended
charging temperatures. For more
information, see Equipment Ratings on
page 15.
Red, fast blinking Charge or temperature error.
Red, steady for 5 seconds The battery level is too low to start the
unit.
White The unit is starting up.
Not connected to
an external
power source
Off The unit is not connected to an external
power source.
Red, steady for 5 seconds The unit is off and the battery level is
too low to start the unit.
White The unit is starting up.
