Displaying or Hiding the Overlay
Displaying or Hiding the Overlay
The overlay is shown by default after an analysis. The application displays a
circle around each of the active fibers.
The overlay shows the status of the analysis, the status per zone, the
analysis zones and any anomaly (defects and scratches) found on the fiber
endface. The different regions on a fiber such as the core, the cladding and
the adhesive are represented with circles.
The color of the circles shows the status of the analysis zone:
green: pass
red: fail
blue: no analysis performed
The overlay applied on a specific fiber in a multi-fiber connector is
independent from the overlay of the whole connector. You can show or
hide the overlay from the connector overview (where several fibers are
visible at a time) or from the view showing a specific fiber.
To display or hide the overlay:
Tap the icon.
OR
Tap either anywhere in the non-active area (gray background) of the image
or directly on the image of the fiber when you view a specific fiber.
