Extra EA 400 - Page 193

Pilot’s Operating Handbook Section 5
EXTRA 500 Performance
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
0 5 10 15 20 25 30 35 40 45 50 55 60
Bank angle [°]
Stall speed [KIAS]
Flaps up, Gear up
Associated conditions:
- Weight 2130 kg (4696 lbs.)
- Zero Thrust
- Zero instrument error
Example:
Bank angle: 30°
Stall speed for:
Flaps 15°, Gear down: 72 KIAS
Figure 5-4
Angle of Bank versus Stall Speed (Sheet 2 of 2)
26. January 2011
5-15
