Section 2 Pilot’s Operating Handbook
Limitations EXTRA 500
2.7 Miscellaneous Instrument Markings
Miscellaneous instrument markings are shown in Figure 2-5
below.
Red
Line
Yellow
Arc
Green
Arc
Yellow
Arc
Red
Line
Instrument
Min.
Limit
Caution
Range
Normal
Operating
Caution
or
Max.
Limit
Cabin Altitude, ft 10.000
Cabin Differential
Pressure, (PSI)
0 – 5.5 5.5
Fuel Quantity collector
compartment (LH/RH)
0 l
Fuel Quantity main
compartment (LH/RH)
0 l
Fuel Quantity auxiliary
compartment (LH/RH)
0 l
Figure 2-5
2.8 Aircraft Weight Limitations
Maximum Ramp Weight (Taxi Weight): 2130 kg (4696 lbs.)
Maximum Takeoff Weight: 2130 kg (4696 lbs.)
Maximum Landing Weight: 2000 kg (4409 lbs.)
Maximum Zero Wing Fuel Weight: 1945 kg (4289 lbs.)
Maximum Empty Weight: 1445 kg (3186 lbs.)
(incl. unusable fuel)
Maximum Weight
in Baggage Compartment: 90 kg ( 198 lbs.)
2-12 26. January 2011
