Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
6.5 Equipment List
The equipment list gives a surview of equipment available for
the aircraft, the weight and arm of each item for weight and
balance and by a check, the information if an item is installed in
the aircraft to which this handbook is related. The letter “A”
means, that an item can be used as an alternative to the
respective required and/or standard item, the letter “R” means,
that an item is required for type certification, a “S” means, that
this item is part of the standard equipment, and an “O” means,
that this item is defined as optional equipment of the airplane.
No Item Manufacturer Part No
Weight
[kg]
Arm
[m]
Re-
mark
s/inst.
1 Pilot's operating
handbook
Extra 0B701 0.700 3.400 RS
21 Air Conditioning
1 Shut off & Mass flow
control valve
Enviro Systems 1300495-1 3.300 0.900 RS
1 Temparature
modulating valve
Enviro Systems 1300330 1.043 1.370 RS
1 Primary air to air heat
exchanger
Behr D8026; DWG 37.00578 2.500 1.600 RS
1 Primary air to air heat
exchanger
Aero Classics 8001286 2.500 1.600 RA
1 Cabin Air Mass Flow
Controller
Enviro Systems 1300360-17 0.322 3.700 RS
1 Cabin Air Temperature
Controller
Enviro Systems 1300350-27 0.327 3.700 RS
1 Compressor condensor
module
Enviro Systems 1134410-5 11.800 7.400 S
1 Evaporator FWD Enviro Systems 1134200-81 2.950 3.400 S
1 Evaporator AFT Enviro Systems 1134200-80 2.950 6.250 S
2 Panel Vent Fan Sanyo Denki 9G0624G1021 0.195 2.240 S
1 Cabin Press Indicator U.M.A INC. 11-210-22W 0.142 2.350 RS
1 Cabin Climb Indicator U.M.A INC. 8-210-64W 0.225 2.350 RS
1 Cabin Pressure
Controller
Dukes Inc. 5111-00-3 0.454 2.380 RS
1 Outflow Control Valve Dukes Inc. 5112-00-3 1.450 6.300 RS
1 Outflow Safety Valve Dukes Inc. 5113-00-3 1.270 6.300 RS
26. January 2011 6-23
