Pilot’s Operating Handbook Section 905
EXTRA 500 SHADIN MINIFLO-L
905 SHADIN MINIFLO-L
905.1 Section 1 - General
Important The fuel computer MINIFLO-L does not replace the fuel
quantity gauges.
Note The fuel computer can measure fuel flow but not fuel
amount. It is thus unable to determine the amount of usable
fuel available in the tanks. It is, therefore, essential to
program the computer with the actual amount of usable fuel
in the tanks before each flight in order to ensure exact
information.
905.1.a In-Flight Modes
FUEL FLOW - current consumption
Fuel flow is shown continually in the left display.
ENDURANCE - remaining flight time
If the right knob is turned to “ENDURANCE” the remaining
flight time in hours and minutes appears in the right display.
FUEL USED - fuel used
If the right switch is moved to “FUEL USED” and held, the
amount of fuel consumed since the last setting will appear in the
right display.
FUEL REMAINING - remaining amount of fuel
If the left switch is moved to “FUEL REM” and held, the
amount of fuel currently available will appear in the right
display.
905.1.b Warnings
ENDURANCE
If the right display flashes while the knob is turned to
“ENDURANCE”, maximum possible endurance at the selected
performance settings is less than 30 minutes.
905.2 Section 2 - Limitations
No change.
26. January 2011
905-3
