Extra EA 400 - Page 195

Pilot’s Operating Handbook Section 5
EXTRA 500 Performance
CONDITIONS:
TAKEOFF DISTANCE
Takeoff Rotation Takeoff Rotation
Landing gear down and flaps 15
Weight Speed WeightSpeed
2030 RPM - BLEED 2
LBS KIAS KG KIAS
111 % Torque or 810 Deg.CTOT
4696 71,0 2130 71,0
4600 70,6 2100 70,7
Paved, Level, DryRunway
4400 69,6 2000 69,7
Zero Wind
4200 68,7 1905 68,7
4000 67,7 1900 68,6
1800 67,6
NOTES: Decrease distances 10% for each 10 knots headwind.
3900 67,3 1769 67,3
For operation with tailwind up to 10 knots, increase distances by 10% for each 2.5 knots.
3800 66,8 1700 66,6
For operation on a dry, grass runway, increase distances by40% of the "ground roll" figure. 3600 65,9 1600 65,5
3417 65,0 1550 65,0
SPEED ISA -20 C ISA -10 C ISA ISA +10 C I
SA +20 C ISA +30 C
WEIGHT AT PRESS
LBS 50 FT ALT TOTAL TOTAL TOTAL TOTAL TOTAL TOTAL
(KG) KIAS FT GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
4200 77 S.L. 925 1520 945 1550 965 1585 985 1620 1010 1655 1125 1850
(1905) 1000 955 1570 980 1605 1000 1635 1010 1655 1070 1750 1190 1955
2000 990 1620 1010 1655 1030 1685 1040 1705 1130 1855 1260 2070
3000 1020 1675 1045 1710 1065 1740 1090 1790 1200 1970 1335 2190
4000 1055 1730 1075 1765 1100 1800 1155 1895 1275 2085 1415 2320
5000 1085 1785 1110 1825 1135 1865 1220 2005 1350 2215 1500 2460
6000 1120 1840
1150 1885 1175 1930 1295 2120 1430 2350 1590 2605
7000 1155 1895 1185 1940 1230 2020 1370 2250 1519 2490 1680 2760
8000 1190 1950 1220 2000 1305 2145 1460 2390 1610 2640 1780 2920
9000 1225 2005 1290 2115 1395 2295 1550 2540 1705 2800 1880 3085
10000 1270 2085 1380 2265 1505 2470 1645 2700 1805 2960 1990 3265
Fig 5-5
Takeoff (Sheet 2 of 4)
26. January 2011
