Section 6 Pilot’s Operating Handbook
Weight and Balance and Equipment List EXTRA 500
Sample Weight and Balance Loading Form
Ref Item
Arm
(m)
Weight
(kg)
Moment
(kgm)
1 Basic Empty Weight (Sample) 1425 5095
2 Pilot (Station 2.825 - 2.981) 2.84 86 244.24
3 Copilot (Station 2.825 - 2.981) 2.95 80 236
4
Passenger(s) on Seats 3 + 4 (Station 3.930)
(refer to figure 6-5)
130 510.9
5
Passenger(s) on Seats 5 + 6 (Station 5.050)
(refer to figure 6-5)
50 252.5
6
Baggage (Station 5.750) (Do not exceed max.
weight in baggage compartment of 90 kg).
(refer to figure 6-5)
12 69
7 Zero Fuel Weight (sub-total)
(Do not exceed max. zero fuel weight of 1945 kg)
1783 6407.64
8a
Fuel Loading main compartment
(refer to figure 6-6a)
293 1104
8b
Fuel Loading auxiliary compartment
(if applicable, refer to figure 6-6b)
0 0
9 Ramp Weight (sub-total)
(Do not exceed max. ramp weight of 2130 kg)
2076 7511.64
10 Less Fuel For Taxiing (refer to figure 6-6) 7 26.4
11
Takeoff Weight
(Do not exceed max. takeoff weight of 2130 kg)
2069 7485.24
12a
Less Fuel To Destination main compartment
(refer to figure 6-6a)
195.4 736
12b
Less Fuel To Destination auxiliary compartment
(if applicable, refer to figure 6-6b)
0 0
13
Landing Weight
1873.6 6749.24
Figure 6-3
Sample Weight and Balance Loading Form
6-12 26. January 2011
