Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
No Item Manufacturer Part No
Weight
[kg]
Arm
[m]
Re-
mark
s/inst.
25 Equipment / Furnishings
1 pilotseat assy (1) Extra EA-75430 11.400 2.900 RS
1 pilot seat belt assy Schroth P/N 1-08-115201 1.800 2.970 RS
1 co-pilotseat assy (2) Extra EA-75440 11.400 2.900 RS
1 co-pilot seat belt assy Schroth P/N 1-08-110201 1.800 2.970 RS
1 mid-pax-seat LH (3) Extra EA-75450 6.700 3.930 RS
1 seat belt assy (3) Schroth P/N 5-02-145701 1.400 3.860 RS
1 mid-pax-seat RH (4) Extra EA-75460 6.700 3.930 RS
1 seat belt assy (4) Schroth P/N 5-02-140701 1.400 3.860 RS
1 rear-pax seat LH (5) Extra EA-75470 6.600 5.050 RS
1 seat belt assy (5) Schroth P/N 5-02-140701 1.400 5.120 RS
1 rear-pax-seat RH (6) Extra EA-75480 7.700 5.050 RS
1 seat belt assy (6) Schroth P/N 5-02-145701 1.400 5.120 RS
26 Fire Protection
1 Fire Extinguisher Air Total HAL 1.2; P/N 74-20 2.400 3.400 RS
27 Flight Controls
1 Flap Control Box Kissling 7010707-000100.00;
EA-85411
0.345 3.800 RS
1 Flap Motor Engel GNM 4175A 2.650 3.930 RS
28 Fuel
4 Filler cap Extra EA-6B215.02 0.105 3.650 RS
2 Fuel quantity indicator
collector compartment
UMA T18 112F 1000 AAW 0.120 2.240 RS
2 Fuel quantity indicator
main tank
UMA T18 112F 1010 ABW 0.120 2.240 RS
2 Fuel quantity indicator
long range tank
UMA T18 112F 1020 ACW 0.120 2.240 RS
1 Fuel selector valve
(incl. Shut-off)
Allen Airctaft 8BS1001 0.200 2.950 RS
1 Fuel filter Assembly Purolator 1743640-06 0.800 1.343 RS
2 El. fuel pump Parker /
Airborne
2B7-40 1.400 1.880 RS
1 Pressure accumulator Extra EA-6B236.00 0.840 1.600 RS
2 Motive Flow Filter Sobek Z-C 1000 0004 0.150 3.000 RS
2 Motive flow pump Pierburg 7.21440.68.0 0.300 3.050 RS
26. January 2011 6-25
