Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
No Item Manufacturer Part No
Weight
[kg]
Arm
[m]
Re-
mark
s/inst.
6 Reading Light Rocamarine 467810 0.100 4.000 RS
2 Map Light Spruce 11-07800 0.050 3.000 RS
1 Landing light Xe Vision XV-19 0.590 0.730 RS
34 Navigation
2 IFD (L+R) Avidyne IFD5000i;
HW: 700-00083-000;
SW: 530-00218-000
8.100 2.200 RS
1 Keypad/Display Avidyne ACD215;
HW: 700-00150-002;
SW 530-00205-000
1.040 2.600 RS
1 Aircraft Configuration
Module
Avidyne AMC100;
HW: 700-00156-xxx
0.090 2.200 RS
2 Magnetometer Avidyne MAG300;
700-00011-000;
SW 530-00124-000
0.250 3.500 RS
1 DME Bendix / King KDM 706A; 066-1066-25 2.500 6.866 RS
1 DME-Indicator Bendix / King KDI-574; 066-1069-04 0.320 2.300 RS
1 Turn Coordinator S-Tec 6405-28L 0.820 2.250 RS
1 Magnetic direction
indicator
Airpath C 2400-L4VT 0.300 2.450 RS
2 pitot tube (heated) Aeroinstruments AN5812-1 0.400 3.790 RS
2 dual static port
(heated)
Extra EA-75123.10 0.120 7.000 RS
1 Lift Detector Safe Flight C-88807-3 0.135 3.400 RS
1 Standby Gyro Mid-Continent 4200-11 0.730 2.240 RS
1 Standby Airspeed
Indicator
Aerosonic 25025-0177 0.340 2.240 RS
1 Standby Airspeed
Indicator
Mid-Continent MD25-260 0.270 2.240 RA
1 Standby Altitude
indicator
Aerosonic 15035-01107 0.370 2.240 RS
1 Standby Altitude
indicator
United
Instruments
UI5237AMR-A.918 0.410 2.240 RA
1 Standby Altitude
indicator
United
Instruments
UI5237AR-A.916 0.410 2.240 RA
1 TAS 610 Unit /
Processor
Avidyne 70-2420-[] 2.550 6.150 O
1 Thunderstorm
Detection Processor
Avidyne TWX 670;
700-00033-000-[00]
0.640 4.100 O
36 Pneumatic
1 Pressure regulator BF-Goodrich 4D2095-183 0.620 1.340 RS
1 automatic water
separator
BF-Goodrich 3D3553-01 0.454 1.850 RS
26. January 2011 6-27
