Pilot’s Operating Handbook Section 7
EXTRA 500 Description of Airplane and Systems
Propeller reduction
gearbox
Compressor
Power
and
accessory
gearbox
Turbine
Combustion
section
Figure 7-9
Engine Main Components
26. January 2011 7-27
