Pilot’s Operating Handbook Section 7
EXTRA 500 Description of Airplane and Systems
Switch
Unit
Annunciator light
Gauge
Selector valve
Check valve
Drain valve
Filter (with drain valve)
Pump
Nozzle
Fuel filter opening
Jet pump
Low fuel level switch
Overpressure valve
Fuel level sensor
Float valve
Electric wiring
Flow direction
FUEL
PRESS
Legend:
Figure 7-14
Fuel System Schematic (Sheet 2 of 2)
26. January 2011 7-45
