Extra EA 400 - 904.1 Section 1 - General

Pilot’s Operating Handbook Section 904
EXTRA 500 BENDIX/KING KDM 706A
904 BENDIX/KING KDM 706A
904.1 Section 1 - General
The KDM 706A is a remote mounted 200 channel DME.
Range, speed and time to station are displayed on the KDI 574
indicator on the left lower side of the main panel. Frequency
selection is performed on the center console keyboard by
pressing the AUX button. NAV1, NAV2, NAV1 HOLD and NAV2
HOLD can be selected from the display using the FMS knob on
the right lower side of the keyboard.
An additional hold function is provided by the
DME HOLD
switch located next to the KDI 574 indicator. Always the active
frequency is held independent from the selection made on the
keyboard. If this hold function is active, the switch will light
HOLD (blue).
904.2 Section 2 - Limitations
No change.
904.3 Section 3 - Emergency Procedure
No change.
904.4 Section 4 - Normal Procedure
No change.
904.5 Section 5 - Performance
No change.
26. January 2011
904-3
