Take care to load the rack so that it is not top-heavy. Start installing equipment at the bottom and work
up.
Note
The X440-G2 and X620 switches can be front-mounted or mid-mounted to a two-post rack
only. They cannot be attached to a four-post rack or cabinet.
1. On one side of the switch, set a mounting bracket against the switch housing.
Set the flange even with the front panel of the switch – or, if you are mid-mounting the switch in a
two-post rack, set the flange toward the back of the switch.
The following figures illustrate how to attach the brackets for two common mounting options.
• Figure 169 shows a mid-mount configuration using a long mounting bracket.
• Figure 170 shows a front-mount
configuration using a short mounting bracket.
Note
For some switch models, only short mounting brackets are provided.
Figure 169: Mid-Mount: Attaching a Long Mounting Bracket
Attaching the Switch to a Rack or Cabinet
Installing Your Extreme Networks Switch
224 ExtremeSwitching Hardware Installation Guide
