b. Insert the screws and fully tighten them using a screwdriver.
Figure 206: Attaching the Mounting Bracket to the EPS-C2 Chassis
c. Attach the mounting bracket for the other side of the EPS-C2.
4. Slide the EPS-C2 into the rack and secure it using appropriate rack-mount screws.
See Figure 207.
Figure 207: Sliding the EPS-C2 into the Rack and Securing it
Installing an EPS-C2 Chassis
Installing External Power Supplies
266 ExtremeSwitching Hardware Installation Guide
