Chapter 1: Summit Family Switches
Summit Family Switches Hardware Installation Guide
106
Additional Port LED meanings for PoE switches: Summit X450e-24p & Summit X450e-48p
All front-panel ports Steady amber Port is powered with link, no traffic.
Blinking amber Port is powered with link, traffic.
Slow blinking amber Port is powered, with no link.
Alternating amber and
green
Port has a fault.
Off Port is not powered, has no link, or is disabled.
Rear Panel
Management Port Steady green Link OK
Blinking green Activity
Stacking Port Steady green Link OK
Blinking green Activity
SFP 1G Port
(on installed option card)
Steady green Link OK
Blinking green Activity
XENPAK 10G Port
(on installed option card)
Steady green Link OK
Blinking green Activity
XFP 10G Port
(on installed option card)
Steady green Link OK
Blinking green Activity
Table 29: LEDs on the Summit X450, X450a, and X450e Switches (Continued)
Label or Type Color/State Meaning
