Extreme Networks Summit X460 Series User Manual

Chapter 6: Installing Summit Family Switches
Summit Family Switches Hardware Installation Guide
242
Mid-Mounting a Switch in a Two-Post Rack
To mid-mount a Summit X460 series switch in a two-post rack:
1 Attach an ESD-preventive wrist strap to your bare wrist and connect the metal end to an appropriate
ground point on the rack.
2 On one side of the switch, set the bracket against the switch housing, with the flange toward the
back of the switch (see Figure 180).
3 Use six of the provided screws to secure the bracket to the switch housing.
4 Repeat step 2 to attach the other bracket to the other side of the switch.
Figure 180: Attaching a Rack-mounting Flange
5 Slide the switch into the equipment rack (Figure 181).
Figure 181: Installing the Summit X460 Series Switch
SH_197
SH_198
