Summit X440 Series Switches
Summit Family Switches Hardware Installation Guide
77
Summit X440 Series Switch LEDs
Table 16 describes the meanings of the LEDs on the Summit X440 series switches.
Table 16: LEDs on the Summit X440 Series Switches
Label or Type Color/State Meaning
Front Panel
MGMT Blinking green Power-on self-test (POST) in progress.
Steady green POST passed. Normal operation.
Blinking amber System is disabled. POST failed or system overheated.
Off No external power attached.
FAN Steady green Normal operation, fan is good.
Note:
For the following Summit models, fan light is “ON” only when the
fan is running:
Summit X440-24t model No. 800471-00 Revision 6 or lower
Summit X440-24t-10G model No. 800475-00 Revision 5 or lower
Summit X440-L2-24t model No. 800526-00 Revision 1
Blinking amber Fan failure. Switch will continue to operate unless it overheats.
Off No power
Note:
For the following Summit models, fan light “OFF” indicates either
no power to the fan or temperature is below threshold where fans
are needed:
Summit X440-24t model No. 800471-00 Revision 6 or lower
Summit X440-24t-10G model No. 800475-00 Revision 5 or lower
Summit X440-L2-24t model No. 800526-00 Revision 1
PSU-I
(Internal power
supply)
Steady green Normal operation.
Steady amber Power is attached, but no power is on.
Blinking amber Power failure.
Off No power is attached.
PSU-E
(External power
supply)
Steady green Normal operation.
Steady amber Power is attached, but no power is on.
Blinking amber Power failure.
Off No external power attached.
Port number
1 – 8 or
1 – 24 or
1 – 48
Steady green Link is OK.
Blinking green Port is transmitting packets.
Off Link is not present, or port is disabled.
Port number
21 – 24 or
45 – 48
(Shared ports)
Steady green Link is OK.
Blinking green Port is transmitting packets.
Off Link is not present, or port is disabled.
Port number
25 – 26 or
49 – 50
(10G ports)
Steady green Link is OK.
Blinking green Port is transmitting packets.
Off Link is not present, or port is disabled.
