Appendix B: Technical Specifications
Summit Family Switches Hardware Installation Guide
478
Summit X670 Series Switches
The Summit X670 series includes the following switches:
● Summit X670-48x switch
● Summit X670V-48x switch
● Summit X670V-48t switch
Table 90: Summit X670 Series Switch Technical Specifications
Physical Dimensions
Summit X670-48x switch
Summit X670V-48x switch
Height: 1.73 inches (4.4 cm)
Width: 17.4 inches (44.1 cm)
Depth: 20.4 inches (51.9 cm) including PSU and installed fan module
Summit X670V-48t switch Height: 1.73 inches (4.4 cm)
Width: 17.6 inches (44.8 cm)
Depth: 20.4 inches (51.9 cm) including PSU and installed fan module
VIM4-40G4X module Height: 1.6 inches (4.1 cm)
Width: 4.1 inches (10.3 cm)
Depth: 6.5 inches (16.6 cm)
Summit X670 fan module Height: 1.65 inches (4.2 cm)
Width: 1.65 inches (4.2 cm)
Depth: 3.98 inches (10.1 cm)
Weight
Summit X670-48x switch 16.0 lb (7.3 kg)
Summit X670V-48x switch 15.3 lb (7.0 kg)
Summit X670V-48t switch 16.9 lb (7.7 kg)
NOTE: Switch weights include installed fan module. They do not include installed VIM4 modules or power
supplies.
VIM4-40G4X module 0.99 lb (0.45 kg)
Summit X670 fan module 0.36 lb (0.16 kg)
Packaged Dimensions
Summit X670-48x switch
Summit X670V-48x switch
Summit X670V-48t switchch
Height: 6.5 inches (16.5 cm)
Width: 23.4 inches (59.3 cm)
Depth: 26.2 inches (66.5 cm)
VVIM4-40G4X module Height: 3.9 inches (10 cm)
Width: 9.4 inches (24.0 cm)
Depth: 15.4 inches (39 cm)
Packaged Weight
Summit X670-48x switch 22.7 lb (10.3 kg)
Summit X670V-48x switch 21.2 lb (9.6 kg)
Summit X670V-48t switch 22.7 lb (10.3 kg)
VIM4-40G4X module 2.75 lb (1.25 kg)
Summit X670 fan module 1.27 lb (0.58 kg)
Fan Speed
Minimum speed 4500 RPM
Maximum speed 18000 RPM
