Installing Summit X650 Power Supplies
Summit Family Switches Hardware Installation Guide
281
Figure 229: Securing the Switch to the Front Rack Posts—Cabinet Installation
After the switch is secured to the rack, install and connect power supplies as described in “Installing an
850 W AC Power Supply in a Summit X650 Series Switch” or “Installing an 850 W DC Power Supply in
a Summit X650 Series Switch” on page 284.
Installing Summit X650 Power Supplies
The Summit X650 series switch is shipped without installed power supplies. The switch accommodates
one or two Summit 850 W power supply units.
AC Power Supply Cords
An AC power cord is not included with the Summit 850 W AC power supply. You can purchase AC
power cords for use in the US and Canada from Extreme Networks or from your local supplier. The
cord must meet the following requirements listed in
“Power Cord Requirements for AC-Powered Switches
and AC Power Supplies” on page 500
.
SH_084
