Installing a Summit X460 Series Switch
Summit Family Switches Hardware Installation Guide
241
Installing a Summit X460 Series Switch
The Summit X460 series switch fits into a standard 19-inch equipment rack. The provided rack-
mounting brackets attach to the front of the switch unit and are adaptable to either a front-mount or
mid-mount installation.
The installation process includes the following tasks:
1 Install the switch in the rack.
2 Install the first power supply.
3 (Optional) Install a second power supply.
4 (Optional) Install a port option card or stacking module, or both.
5 Connect power cables.
6 For a stacked configuration, connect stacking cables
7 Connect network interface cables.
If you are installing Summit X460 series switches for use in a SummitStack configuration, read Chapter
5, “Building a SummitStack Configuration,” before you install the switches.
NOTE
Take care to load the rack so that it is not top-heavy. Start installing equipment at the bottom of the rack
and work up.
Pre-installation Requirements
Installing the Summit X460 series switch requires two people to maneuver the switch and attach
mounting hardware.
Make sure there is adequate space behind the rack to provide access for installing power supplies, port
option cards, and stacking modules.
The following items are provided with the Summit X460 series switch:
● Two rack mounting brackets adaptable for either a front-mount or mid-mount installation
● Twelve screws for attaching the brackets to the switch enclosure
You need the following additional tools and equipment:
● Four rack mounting screws
The screw size will vary based on your organization’s rack system; screws are not provided.
● Screwdriver for securing the switch to your organization’s rack
The screwdriver size will vary based on the requirements of your organization’s rack system.
● AC power cord for each installed AC power supply
An AC power cord is not included with the Summit X460 series switch. You must obtain a power
supply cord that meets the requirements listed under
“Power Cord Requirements for AC-Powered
Switches and AC Power Supplies” on page 500
.
● ESD-preventive wrist strap for installing optional ports at the back of the switch
